DiTemp Self Heating Cable

Downloads

Distributed fiber optic temperature sensor with self-heating capability for civil, geotechnical monitoring, and leak detection.

The Self-heating cable is a unique sensor for the evaluation of distributed temperature over distances up to 1 km.

The Self-heating Cable is used in a range of hydro & geotechnical applications that require distributed temperature sensing, where the temperature contrast between the ground and the fluid to be monitored is not sufficient to provide reliable detection. The Self-heating cable is particularly used in the seepage monitoring of dams, dikes, embankments, and levees, just to name a few.

The Self Heating Cable is a small fiber optic cable, armored with stainless steel loose tube gel-filled, stainless steel strength members and HDPE outer sheath. The central loose tube is hermetically sealed and contains four bend-insensitive fibers with a dual-layer acrylate coating for increased micro-bending performance. The additional wiring, made of copper wires, permits to heat the cable thanks to the low resistivity.

This sensor is particularly suitable for outdoors and harsh environment applications with different methodologies of installation: direct burial in the ground or concrete.

Thanks to the special package design, the Self Heating Cable offers high tensile strength, crush resistance, lateral water tightness, chemical and abrasion resistance, and excellent rodent protection.

The Self Heating Cable is fully compatible with the DiTemp system and all its accessories.
